Type:
Bug
-
Resolution: resolved
-
Priority:
Major
-
Component/s: None
-
None
Using the rogue at prelease:
(rogue_pre-release) ruckman@rdsrv307:~/projects/sparkPix-S/software$ python scripts/devGui --dev sim Rogue/pyrogue version v4.10.15-270-gfeef5de2. https://github.com/slaclab/rogue
Here's the FW:
axiSlaveRegisterR(axilEp, x"7FC", 0, toSlv(DATA_WIDTH_G, 8));
axiSlaveRegisterR(axilEp, x"7FC", 8, toSlv(NUM_LANE_G, 8));
Here's the SW:
self.add(pr.RemoteVariable(
name = 'DATA_WIDTH_G',
offset = 0x7FC,
bitSize = 8,
bitOffset = 0,
mode = 'RO',
disp = '{:d}',
))
self.add(pr.RemoteVariable(
name = 'NUM_LANE_G',
offset = 0x7FC,
bitSize = 8,
bitOffset = 8,
mode = 'RO',
disp = '{:d}',
))
I have confirmed that the issue goes away if I revert to an arbitary older release of rogue:
(rogue_pre-release) ruckman@rdsrv307:~/projects/sparkPix-S/software$ conda deactivate ruckman@rdsrv307:~/projects/sparkPix-S/software$ conda activate rogue_4.10.16 (rogue_4.10.16) ruckman@rdsrv307:~/projects/sparkPix-S/software$ python scripts/devGui --dev sim Rogue/pyrogue version v4.10.16. https://github.com/slaclab/rogue start: Started zmqServer on port 9099 QStandardPaths: XDG_RUNTIME_DIR not set, defaulting to '/tmp/runtime-ruckman' Setting timeout to 1000 msecs, waitRetry = 1 Connected to Root at localhost:9099 Running GUI. Close window, hit cntrl-c or send SIGTERM to 2152342 to exit.
- duplicates
-
-
- Done
-
